    Post by Guest Mon Sep 08, 2014 8:49 pm

    My version of the M125 getting close to first power up!
    Front face panel will have a mini retro look VU meter. I will be using 4x KT120's, the transformers are currently being sprayed satin black.

    photo fats2_zps85d4642e.jpg

    photo fats1_zps3bc7fc68.jpg

    photo fats3_zps7a12720a.jpg
    • Back to top
    carpenter
    avatar
    carpenter


    Posts : 4
    Join date : 2014-08-20
    • Post n°2

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by carpenter Tue Sep 09, 2014 5:06 am

    Lovely! I love how you drilled your vent holes with such precision. Now you need a front/side view of the chassis.

    I've been thinking of using star or hex bolts to avoid that cluttered look of misaligned screw heads.

    I'm also considering placing the speaker ground post in between the 4 ohm and 8 ohm posts. That way, all I have to do is flip the speaker's banana jack 180 degrees to alternate between 4 or 8 ohms.
    • Back to top
    mazeeff
    avatar
    mazeeff


    Posts : 155
    Join date : 2014-01-06
    Age : 69
    Location : Grand Rapids, Michigan, USA
    • Post n°3

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by mazeeff Tue Sep 09, 2014 5:40 am

    Tell us more about that little mini-fan. How are you powering it?

    Mike
    • Back to top
    Guest
    avatar
    Guest
    Guest


    • Post n°4

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Guest Tue Sep 09, 2014 8:40 am

    carpenter wrote:Lovely! I love how you drilled your vent holes with such precision. Now you need a front/side view of the chassis.

    I've been thinking of using star or hex bolts to avoid that cluttered look of misaligned screw heads.

    I'm also considering placing the speaker ground post in between the 4 ohm and 8 ohm posts. That way, all I have to do is flip the speaker's banana jack 180 degrees to alternate between 4 or 8 ohms.

    I wish I could take credit on the plate drilling....but alas....I cannot, it is all professionally done on a CNC milling machine by Front Panel Express. I could never do such precision work.
    I will take the credit for designing the layout though and laying out the vent holes Smile
    The front panel too is all done, I am still waiting on the gauges etc., once I have those will take more photo's.
    The transformers have been painted and I 'll be able to mount those later today and start on the wiring.
    • Back to top
    Guest
    avatar
    Guest
    Guest


    • Post n°5

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Guest Tue Sep 09, 2014 8:47 am

    mazeeff wrote:Tell us more about that little mini-fan. How are you powering it?

    Mike

    the ones I use are a mini 12VDC unit, I buy them in bulk from Hong Kong. At full 12V, they are not the quietest, so I have made up a very simple variable DC power supply using an LM317 regulator, in a TO220 package, and drive them at about 8VDC, I found at that setting they are very quiet and still move plenty of air. Being a variable power supply, I can fine adjust that fan supply voltage to arrive at the best/least 'noise setting'.
    I use a mini fully encapsulated transformer for the 15VAC supply, that same transformer also supplies the VU meter driver board.
    I am using the fans to push air into the chassis. Hot tubes, by the nature of heat, draw air 'out' of a chassis through vent holes, that small fan supplies cooler ambient air into the chassis to aid in the tube cooling.
    • Back to top
    MarcVBelgium
    MarcVBelgium
    MarcVBelgium


    Posts : 116
    Join date : 2013-12-06
    Age : 70
    Location : Antwerp, BELGIUM
    • Post n°6

    VTA M-125 in custom chassis Empty M-125 in custom chassis

    Post by MarcVBelgium Tue Sep 09, 2014 11:16 am

    This work is just BEAUTIFUL

    Congrats on the work so far..... it's a great job!
    • Back to top
    Bob Latino
    Bob Latino
    Bob Latino
    Admin


    Posts : 3262
    Join date : 2008-11-26
    Location : Massachusetts
    • Post n°7

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Bob Latino Tue Sep 09, 2014 11:27 am

    Holger,

    Excellent work on that custom version of the VTA M-125 monoblock amp. Yes - post up a photo of the wiring when you get the amp wired ..

    Bob
    • Back to top
    audiobill
    avatar
    audiobill


    Posts : 425
    Join date : 2014-03-13
    Location : Albany, NY
    • Post n°8

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by audiobill Tue Sep 09, 2014 4:30 pm

    Is that the "soft start" board I see in there?
    • Back to top
    Guest
    avatar
    Guest
    Guest


    • Post n°9

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Guest Tue Sep 09, 2014 4:32 pm

    audiobill wrote:Is that the "soft start" board I see in there?

    it is indeed, I believe that is a great addition to any tube amp in extending power tube life, and the extra cost is minimal
    • Back to top
    Guest
    avatar
    Guest
    Guest


    • Post n°10

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Guest Mon Sep 15, 2014 9:26 pm

    well, the beasty is alive...and sounds just so wonderful!...I had the volume pot wired the wrong way, nearly blew the test speakers off the wall!!!!!!!...not to mention my eardrums!!
    Powere straight up, no worries.

    The wiring is still somewhat temp, I am waiting for the correct handed front panel, the one in the photo is for a 'left handed' chassis, the amp in the photo is actually a 'right handed' chassis.

    photo bbopper2_zpsaba102cb.jpg

    photo bbopper3_zps5cc3ef0b.jpg

    photo bbopper4_zps184d1187.jpg

    photo bbopper5_zpsa89c8485.jpg

    photo bbopper1_zpsd78beff7.jpg
    • Back to top
    colin86325
    avatar
    colin86325


    Posts : 61
    Join date : 2014-04-01
    • Post n°11

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by colin86325 Tue Sep 16, 2014 6:43 am

    She's a beauty!
    On a side note, would there be an improvement if you clocked one of the chokes 90 degrees?
    • Back to top
    Bob Latino
    Bob Latino
    Bob Latino
    Admin


    Posts : 3262
    Join date : 2008-11-26
    Location : Massachusetts
    • Post n°12

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Bob Latino Tue Sep 16, 2014 9:21 am

    colin86325 wrote:She's a beauty!
    On a side note, would there be an improvement if you clocked one of the chokes 90 degrees?

    The chokes are mainly passing DC .. They are there to "choke off" small amounts of AC riding on the DC before the audio signal is dropped onto the DC B+. Because almost no AC is passing through the choke, there is virtually no interaction either between the two chokes or between the chokes and the power transformer.

    Bob
    • Back to top
    Guest
    avatar
    Guest
    Guest


    • Post n°13

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Guest Tue Sep 16, 2014 9:28 am

    Bob Latino wrote:
    colin86325 wrote:She's a beauty!
    On a side note, would there be an improvement if you clocked one of the chokes 90 degrees?

    The chokes are mainly passing DC .. They are there to "choke off" small amounts of AC riding on the DC before the audio signal is dropped onto the DC B+. Because almost no AC is passing through the choke, there is virtually no interaction either between the two chokes or between the chokes and the power transformer.

    Bob

    you took the words right out of my mouth! :-)
    • Back to top
    Guest
    avatar
    Guest
    Guest


    • Post n°14

    VTA M-125 in custom chassis Empty Re: VTA M-125 in custom chassis

    Post by Guest Tue Sep 16, 2014 3:27 pm

    .


    Last edited by PeterCapo on Thu Dec 03, 2020 11:15 pm; edited 1 time in total
